| CPU | RK3128 Quad-Core A7 Frequency 1.2G |
| GPU | Mali-400 MP2 Dual-Core |
| （Decode with hardware 1080P H.264和10bits H.265） | |
| Storage | 1GB DDR3 |
| 8GB Emmc | |
| OS | Android5.1/liunx kernel 3.1 |
| Ethernet | 10M/100M |
| Wi-Fi | 2.4Ghzwifi support 802.11b/g/n |
| Bluetooth | Bluetooth4.0 |
| Screen | 8 inch, 1024*600, IPS Full Perspective,800cd |
| Build-in Camera | 1080P 15fb/s support infrared |
| Camera IP | 1080P 15fb/S docking with the public security system |
| Audio | Bulit-in speaker 3W Audio Playback |
| TF | support TF |
| 4G | Optional |
| Key | 3*4 mechanical keyboard with light, Reset |
| Interfaces | 1*12V Power Port |
| 1*MicroTF | |
| 1*microSIM | |
| 2*Open signal interface | |
| 1*RS485 | |
| 2*RJ45 | |
| 1*HOST USB2.0 | |
| 1*Door magnetic detection interface | |
| 1*Smoke alarm interface | |
| Work Environment | -10~70℃ |
| Function | Support phone and tel open door, Support IC card/QR scan open door, Support message authorization open, Support smoke detection and alarm |
